OLABO Biosafety Transport Box
Product Introduction
This product is suitable for the on-site sampling and carrying of high-risk and infectious biological substances, and the transportation or carrying of samples and bacteria (virus) strains.
Features
1. The main container and the secondary container must be able to withstand a pressure difference of 95kPa in the temperature range of -40℃ to +55℃ without leakage;
2. Three-layer packaging (all composed of main container, secondary container and outer packaging)
3. The complete package must be able to pass the test method specified in the "Technical Rules for the Safe Transport of Dangerous Goods by Air";
(Including drop test, outer packaging water spray test, perforation test, differential pressure test, and additional frozen drop test)
4. The secondary container is equipped with adsorbent materials, which can completely adsorb the sample under the condition of accidental leakage during transportation;
Technological Parameter
Model
OLB-L6
OLB-L12
External Size(W*D*H)
330*235*275mm
400*250*300mm
Internal Size(W*D*H)
240*145*180mm
330*170*230mm
Capacity
6L
12L
Internal and external materials
PP
Insulation material
PU
polyurethane integral foaming
Temperature type
Cold
storage:2-8℃
Freezing:-12~-22℃
Number of specimens
19
samples at one time
38
samples at one time
Freezing characteristics
When
frozen into solid, the maximum thickness of the cold source is not more than
15% of the unfrozen thickness
Ice source materials
Polyethylene
efficient cold source, firm and safe, no irritation to skin
Storage Time(Ambient 48℃)
24
hours at 2-8 ℃
One
cabinet, one digital thermometer and one strap
Product configuration
One
95kpa biosafety transport tank, one sponge reagent tube holder, one
adsorption cotton and four crystal ice storage boxes
Two
95kpa biosafety transport tanks, two sponge reagent tube holders, two
adsorption cotton sheets, six crystal ice storage boxes
one clapboard and one tray
Gross Weight:
2.9kg
4.2kg
Package Size(W*D*H):
340*250*280mm
420*260*310mm
